| Certificates | |
| Certification | CPR class Cca |
| Features | |
| AWG wire size | 22/1 |
| Bend radius (min) | 8 mm |
| Cable class | D |
| Cable fire class | Cca |
| Cable length | 500 m |
| Cable shape | Round |
| Cable shielding | S/FTP (S-STP) |
| Cable standard | Cat7a |
| Cabling technology | 10GBase-T |
| Conductor material | Copper |
| Conductor type | Solid |
| Connector 1 | No |
| Connector 1 gender | No |
| Connector 2 | No |
| Connector 2 gender | No |
| Data transfer rate | 10000 Mbit/s |
| Frequency | 1500 MHz |
| Jacket material | Low smoke zero halogen (LSZH) |
| Networking standards | IEEE 802.5 |
| Networking standards | IEEE 802.3 |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) type supported | PoE+, PoE++ (4PPoE) |
| Product colour | Yellow |
| Operational conditions | |
| Operating temperature (T-T) | -20 - 60 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Other features | |
| Impedance | 100 Ω |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| Packaging data | |
| Package depth | 550 mm |
| Package height | 350 mm |
| Package volume | 105.875 cm³ |
| Package weight | 35 kg |
| Package width | 550 mm |
| Sustainability | |
| Doesn't contain | Halogen |
| Weight & dimensions | |
| Outer diameter | 7.8 mm |
