| Inputs | |
| HDMI in | 1 |
| USB connector type | Micro-USB |
| Operational conditions | |
| Operating relative humidity (H-H) | 20 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Outputs | |
| Audio (L/R) out | 1 |
| Headphone out | Yes |
| Packaging data | |
| Cables included | USB Type-A to Micro-USB Type-B |
| Manual | Yes |
| Package depth | 105 mm |
| Package height | 65 mm |
| Package type | Box |
| Package weight | 174 g |
| Package width | 146 mm |
| Quantity | 1 |
| Power | |
| Input voltage | 5 V |
| Power consumption | 500 mA |
| Technical details | |
| CEC pass-through | Yes |
| Certification | California Proposition 65 |
| Chipset | SPHE8107S |
| Compliance certificates | Federal Communications Commission (FCC) |
| Compliance certificates | REACH |
| Compliance certificates | RoHS |
| Compliance certificates | CE |
| Frequency range | 20 - 20000 Hz |
| HDMI version | 1.4 |
| Housing material | Plastic |
| Output impedance | 100 Ω |
| Product colour | Silver |
| Signal-to-Noise Ratio (SNR) | 101 dB |
| Supported sample rates | 192 kHz |
| Sustainability compliance | Yes |
| Warranty period | 2 year(s) |
| Weight & dimensions | |
| Depth | 65 mm |
| Height | 27 mm |
| Weight | 81 g |
| Width | 70 mm |
