| Design | |
| Country of origin | China |
| LED indicators | Activity |
| LED indicators | Power |
| Mounting type | Wall |
| Product colour | Black |
| Logistics data | |
| Master (outer) case gross weight | 7 kg |
| Master (outer) case height | 260 mm |
| Master (outer) case length | 360 mm |
| Master (outer) case width | 370 mm |
| Master (outer) cases per pallet (air) | 15 pc(s) |
| Pallet gross length | 80 cm |
| Pallet gross width | 120 cm |
| Pallet height (air) | 160 cm |
| Products per master (outer) case | 12 pc(s) |
| Network | |
| Networking standards | IEEE 802.3af |
| Networking standards | IEEE 802.3bt |
| Networking standards | IEEE 802.3u |
| Networking standards | IEEE 802.3at |
| Networking standards | IEEE 802.3x |
| Networking standards | IEEE 802.3 |
| Networking standards | IEEE 802.3ab |
| Operational conditions | |
| Operating relative humidity (H-H) | 0 - 95% |
| Operating temperature (T-T) | -40 - 75 °C |
| Storage relative humidity (H-H) | 0 - 95% |
| Storage temperature (T-T) | 0 - 90 °C |
| Performance | |
| International Protection (IP) code | IP67 |
| Maximum transfer distance | 100 m |
| Plug and Play | Yes |
| Type | Network repeater |
| Ports & interfaces | |
| Power over Ethernet (PoE) ports quantity | 3 |
| Power | |
| Output voltage | 36 - 57 V |
| Power consumption (typical) | 5 W |
| Power over Ethernet (PoE) | Yes |
| Weight & dimensions | |
| Depth | 73.5 mm |
| Height | 44.3 mm |
| Receiver depth | 16.2 cm |
| Receiver height | 6.4 cm |
| Receiver weight | 630 g |
| Receiver width | 21.1 cm |
| Weight | 380 g |
| Width | 125.8 mm |
