| Features | |
| Antenna connector type | RP-SMA |
| Antenna type | MIMO directional antenna |
| Housing material | Plastic |
| Mounting | Ceiling/wall |
| Polarization | Dual polarization |
| Product colour | White |
| Purpose | Indoor |
| Voltage Standing Wave Ratio (VSWR) | 1,5:1 - 2,5:1 |
| Logistics data | |
| Country of origin | Taiwan |
| Customs product code (TARIC) | 85177000 |
| Harmonized System (HS) code | 85177100 |
| Operational conditions | |
| Operating temperature (T-T) | -20 - 65 °C |
| Packaging content | |
| Cables included | RG-178 |
| Mounting kit | Yes |
| Quantity per pack | 1 pc(s) |
| Packaging data | |
| Package weight | 400 g |
| Performance | |
| Antenna gain (2.4 GHz) | 3 dBi |
| Antenna gain (5 GHz) | 5 dBi |
| Antenna gain level (max) | 5 dBi |
| Frequency band | 2.4 - 5.9 GHz |
| Horizontal beam width (2.4 GHz) | 360° |
| Horizontal beam width (5 GHz) | 220° |
| Impedance | 50 Ω |
| Networking standards | IEEE 802.11ac |
| Networking standards | IEEE 802.11ax |
| Vertical beam width (2.4 GHz) | 55° |
| Vertical beam width (5 GHz) | 40° |
| Weight & dimensions | |
| Depth | 130 mm |
| Height | 45 mm |
| Weight | 208 g |
| Width | 130 mm |
